Have you heard the name Bambi before? For years, it has been the nickname for our smallest single-axle travel trailers. Now, Bambi is an official model, offering space-maximizing options that provide a significant upgrade for tent campers. Bambi takes care of all the small details you need, allowing you to embark on big adventures in a compact trailer.
BAMBI FEATURES
Four Bambi Floor Plans
Each option includes a dedicated sleeping area, a convertible dinette space, a fully equipped kitchen, and an on-board restroom. Discover the floor plan that best suits your adventure needs.
Bambi® 16RB
16 FEET / 1 AXLE / SLEEPS 4
Bambi® 20FB
20 FEET / 1 AXLE / SLEEPS 4
Bambi® 20FB
22 FEET / 1 AXLE / SLEEPS 4
BAMBI SPECS
16RB
Exterior Length
16 ft. 1 in.
Exterior Width
8 ft.
Interior Width
7 ft. 7 in.
Exterior Height with A/C
9 ft. 3 in.
Interior Height with A/C
6 ft. 4 in.
Maximum Trailer Capacity (GVWR) (lbs.)
3,500
Net Carrying Capacity (lbs.)
450
Fresh Water Tank (gal.)
23
Gray Water Tank (gal.)
Waste Water Tank (gal.)
30 (Combo)
Interior Windows and Skylights
7
Sleeping Capacity
Up to 4
Ducted Furnace (BTU)
18,000
Convertible Dinette, Lounge and Bed (inches)
41 in. x 89 in.
Microwave
STD
30 AMP Service Single A/C with Heat Strip (BTU)
13,500
Hitch Weight with LP & Batteries (lbs.)
450
Unit Base Weight with LP & Batteries (lbs.)
3,050
Bedroom Configurations (inches)
48 in. x 78 in.
Refrigerator with Freezer (12v Electric)
3.1 cu. ft.
Solar Charging System with Interior Monitor
OPT 100W
Lithium Batteries (only available w/ solar options) OPT 200Ah 2.4kWh
LP Gas Stove (Burners)
2
20FB
Exterior Length
20 ft. 7 in.
Exterior Width
8 ft.
Interior Width
7 ft. 7 in.
Exterior Height with A/C
9 ft. 3 in.
Interior Height with A/C
6 ft. 4 in.
Maximum Trailer Capacity (GVWR) (lbs.)
5,000
Net Carrying Capacity (lbs.)
1,100
Fresh Water Tank (gal.)
23
Gray Water Tank (gal.)
30
Waste Water Tank (gal.)
18
Interior Windows and Skylights
11
Sleeping Capacity
Up to 4
Ducted Furnace (BTU)
18,000
Convertible Dinette, Lounge and Bed (inches)
39 in. x 74 in.
Microwave
STD
30 AMP Service Single A/C with Heat Strip (BTU)
13,500
Hitch Weight with LP & Batteries (lbs.)
625
Unit Base Weight with LP & Batteries (lbs.)
3,900
Bedroom Configurations (inches)
48 in. x 78 in.
Refrigerator with Freezer (12v Electric)
4.1 cu. ft.
Solar Charging System with Interior Monitor
OPT 200W
Lithium Batteries (only available w/ solar options)
OPT 200Ah 2.4kWh
LP Gas Stove (Burners)
2
22FB
Exterior Length
21 ft. 11 in.
Exterior Width
8 ft.
Interior Width
7 ft. 7 in.
Exterior Height with A/C
9 ft. 3 in.
Interior Height with A/C
6 ft. 4 in.
Maximum Trailer Capacity (GVWR) (lbs.)
5,000
Net Carrying Capacity (lbs.)
1,150
Fresh Water Tank (gal.)
23
Gray Water Tank (gal.)
30
Waste Water Tank (gal.)
17
Interior Windows and Skylights
9
Sleeping Capacity
Up to 4
Ducted Furnace (BTU)
18,000
Convertible Dinette, Lounge and Bed (inches)
39 in. x 74 in.
Microwave
STD
30 AMP Service Single A/C with Heat Strip (BTU)
13,500
Hitch Weight with LP & Batteries (lbs.)
525
Unit Base Weight with LP & Batteries (lbs.)
3,850
Bedroom Configurations (inches)
54 in. x 80 in.
Refrigerator with Freezer (12v Electric)
4.1 cu. ft.
Solar Charging System with Interior Monitor
OPT 200W
Lithium Batteries (only available w/ solar options)
OPT 200Ah 2.4kWh
LP Gas Stove (Burners)
2
